Our vertical machining centers control quality from the very beginning: they utilize a one-piece cast bed, coupled with a high-precision ball screw and servo drive system, achieving positioning accuracy of ±0.003mm and repeatability of ±0.004mm. Even difficult-to-machine workpieces, such as complex curved surfaces and thin-walled parts, can be accurately reproduced from the design drawings, reducing scrap rates by 90%.
| Item | Unit | VMC650 | VMC855 | VMC1160 | VMC1270 | VMC1370 |
| Capacity |
|
|
|
|
|
|
| X axis travel | mm | 600 | 800 | 1100 | 1200 | 1300 |
| Y axis travel | mm | 500 | 550 | 600 | 700 | 700 |
| Z axis travel | mm | 500 | 550 | 600 | 600 | 700 |
| Spindle nose to worktable | mm | 100-600 | 120-670 | 120-720 | 150-800 | 110-810 |
| Spindle center to column | mm | 573 | 550 | 650 | 710 | 750 |
| Leadscrew/Guideway size |
|
|
|
|
|
|
| Leadscrew diameter | mm | 40 | 40 | 40 | 40 | 45 |
| Linear guideway width | mm | 35/35/35 | 35/45/45 | 45/45/45 | 45/55/45 | 45/45/45 |
| Worktable size |
|
|
|
|
|
|
| Worktable Length | mm | 800 | 1000 | 1200 | 1300 | 1400 |
| Worktable width | mm | 500 | 550 | 600 | 700 | 700 |
| T slot qty-width*distance | mm | 5-18*90 | 5-18*90 | 5-18*100 | 7-18*100 | 5-18*110 |
| Max loading capacity | kg | 400 | 500 | 800 | 1000 | 1200 |
| Spindle |
|
|
|
|
|
|
| Spindle speed | rpm | 10000/Belt | 10000/Belt | 10000/Belt | 10000/Belt | 8000/Belt |
| Spindle motor power | kw | 5.5 | 11/15 | 11/15 | 11/15 | 15/18.5 |
| Spindle torque | Nm | 26.3 | 52.5 | 52.5 | 70 | 95.6 |
| Spindle taper |
| BT40 | BT40 | BT40 | BT40 | BT40 |
| Feeding system |
|
|
|
|
|
|
| Fast moving speed (X/Y/Z) | m/min | 36/36/30 | 36/36/36 | 36/36/30 | 36/36/24 | 30/30/24 |
| Cutting speed | mm/min | 1-10000 | 1-10000 | 1-10000 | 1-10000 | 1-10000 |
| Feed motor power | kw | 1.2/1.2/1.8 | 2.0/2.0/3.0 | 3/3/3 | 3/3/3 | 4.5/4.5/4.5 |
| X/Y/Z Axsis motor torque | Nm | 7/7/11 | 12/12/22 | 22/22/22 | 22/22/22 | 37/37/37 |
| Tool Magazine |
|
|
|
|
|
|
| Capacity | pcs | Disc/169 Hat-style | Disc/24 | Disc/24 | Disc/24 | Disc/24 |
| Max tool diameter | mm | 78-90 | 120 | 120 | 120 | 120 |
| Max tool weight | kg | 8 | 8 | 8 | 8 | 300 |
| Max tool length | mm | 250 | 300 | 300 | 300 | 8 |
| Tool change time (TT) |
| 6 | 2.33 | 2.33 | 2.33 | 2.33 |
| Accuracy |
|
|
|
|
|
|
| Positioning accuracy | mm | ±0.004/300mm | ±0.004/300mm | ±0.004/300mm | ±0.004/300mm | ±0.004/300mm |
| Repeat accuracy | mm | ±0.002/300mm | ±0.003/300mm | ±0.003/300mm | ±0.003/300mm | ±0.003/300mm |
