Z3050

Model: Z3050x16/1
Max.drilling diameter: 50mm
Distance from spindle axis to column: 350-1600mm
Horizontal travel of headstock on arm: 1250mm

- PRODUCT PARAMETERS -

Model:	Z3050x16/1
Max.drilling diameter:	50mm
Distance from spindle axis to column:	350-1600mm
Horizontal travel of headstock on arm:	1250mm
Distance from spindle nose to base surface:	320-1220mm
Swivel angle of arm:	±180°
Spindle taper:	MT5
Range of spindle speed:	32-2500rpm
Number of spindle speed:	16steps
Number of spindle feed:	16steps
Spindle travel:	315mm
Power of the main motor:	4kw
Worktable size:	630500500mm
Overall dimension:	Overall dimension
Machine weight:	3500kg
