TCK52DY
10001
With digital control at its core, it breaks through the operational limitations of traditional lathes, transforming complex processes into precise instructions and providing efficient, stable, and consistent machining solutions. The spindle utilizes high-precision bearings for strong vibration resistance, maintaining stable accuracy even during long-term high-speed operation. The bed is constructed from a single piece of cast iron, treated with aging to eliminate internal stress, resulting in minimal deformation and ensuring long-term machining stability.

- PRODUCT PARAMETERS -

With digital control at its core, it breaks through the operational limitations of traditional lathes, transforming complex processes into precise instructions and providing efficient, stable, and consistent machining solutions. The spindle utilizes high-precision bearings for strong vibration resistance, maintaining stable accuracy even during long-term high-speed operation. The bed is constructed from a single piece of cast iron, treated with aging to eliminate internal stress, resulting in minimal deformation and ensuring long-term machining stability.


SpecificationTCK52DY
Maximum swing diameter on the bedΦ670mm
Maximum swing diameter of carriageΦ400mm
distance between centers650mm
Maximum machining length450mm
Spindle nose specificationA2-6
Spindle motor power11-15kw
Spindle unit diameter200mm
Spindle speed4200rpm
Spindle through hole diameterΦ66mm
Inner dia. of pull through holeΦ52mm
Chuck specifications
TypeY-axis of power turnit at station 12
Power tool holderBMT55
X/Z axis travel270/650mm
Y axis travel±45/50mm
X/Z axis screw specifications3210/4010
Repeat positioning accuracy±0.005
Specification of external tool holder25*25mm
Maximum boring bar diameter32mm
Tool change and lock time in adjacent positio0.16s
Tailstock typeHydraulic
Tailstock stroke480mm
Tailstock sleeve diameterΦ80mm
Tailstock sleeve travel100mm
Taper of taper hole of tailstock sleeveMT5
Fast moving speed X/Z20/24M/min
Line width45 Roller mm
Serve motor torque X/Z3/3Kw
